Globe valve, renewable seat, standard port
Forged globe valve with a renewable seat, standard flow port and bolted bonnet. Its principal components are an ASTM A105N body and bonnet, Z20C13 disc and Z12CF13 stem. The remova
Specifications & order
Pressure-seal bonnet globe valve
The pressure-seal globe valve uses a pressure-sealing bonnet construction. Its sectional arrangement places the stem and bonnet assembly above the flow chamber, with a handwheel operating the closure member. This special bonnet arrangement is distinct from a bolted-bonnet globe valve. Specify the material, line connections and pressure-temperature envelope for the pressure-seal configuration itself.
Technical specifications
| Valve type | Globe |
|---|---|
| Bonnet | Pressure seal |
| Operating arrangement | Handwheel |
More products
Globe valve, renewable seat, full port
Full-port globe valve with a renewable seat and bolted bonnet. The construction uses an ASTM A105N forged body and bonnet, Z20C13 disc, and Z12CF13 seat and stem. A renewable seat
Specifications & order
Globe valve, hard-faced seat, bolted bonnet
Forged globe valve with an integral Stellite-hard-faced seat, bolted bonnet and standard flow port. The body and bonnet are ASTM A105N, the disc is Z20C13 and the stem is Z12CF13.
Specifications & order
Globe valve, hard-faced seat, welded bonnet
Forged globe valve with a welded bonnet, integral Stellite-hard-faced seat and full flow port. This arrangement combines an ASTM A105N body and bonnet with a Z20C13 disc, Z12CF13 s
Specifications & order
