Series 200A inverted-bucket steam trap

The 200A series uses an inverted bucket to discharge condensate while retaining steam. A chamber body with a separate cover is shown, with types 213A, 214A, 215A and 216A in the family. The group lists operating pressure up to 32 bar and maximum temperature of 350 °C. Select size, connections and discharge capacity for the actual differential pressure; a capacity figure must not be applied to every type independently of operating conditions.
